Manual & Semi-Electric Stacker
Forklift 1t 1.2t 1.5t 2t
1 to 2 tLithium-ionForks 1220 mm
Price on requestwritten quote
Manual & Semi-Electric Stackers · Ref LPT-56096
500 kg 1100mm Semi Electric Self Loading Pallet Lift Van
0.5 tLead-acidForks 1150 mm
from £1,115per unit, ex VAT
| Quantity | Price per unit |
|---|---|
| 1 to 9 units | £1,155 |
| 10+ units | £1,115 |
Minimum order 1 unit from the factory; any range minimum is confirmed on your quote. Prices in GBP per unit, ex VAT. We convert the factory list at a buffered exchange rate, so normal day-to-day currency movement does not change the price you see. Your written quote adds freight, duty and VAT and is valid for 30 days.
Rated Loading Capacity500kg
Max. Lifting Height1100mm 1300mm
Truck TypeSemi Electric Self Loading Pallet Lift
Line total
No online payment. The basket becomes an order request and we reply with a written GBP quote, deposit 30% on order, lead time 8 to 12 weeks.
Or email [email protected]Product Highlights
Professional Semi Electric Self Loading Stacker 500kg capacity for efficient truck loading.
Versatile Self Lifting Pallet Lift with 1100mm lift height designed for vans and containers.
Compact Van Loading Stacker enables easy cargo transport without external loading docks.
Efficient Semi-Electric Truck Loader featuring 0.8kW lift motor for fast pallet handling.
Portable Self Loading Forklift with 1100mm turning radius for ultra-narrow aisle operation.
Durable Battery Powered Self Loader with PU/Nylon wheels ensures smooth stable movement.
Lightweight 500kg Self Lifting Stacker 197kg net weight for easy mobile delivery tasks.
High-performance Walkie Pallet Lifter with 12V/33Ah battery for reliable logistics service.
Reliable Semi Electric Van Stacker improves productivity and reduces labour in closed areas.
Strategic Truck Pallet Jack solution for e-commerce, express delivery, and retail stores.
| Condition | New |
|---|---|
| Forklift Battery Type | Lead–Acid Battery |
| Drive Type | AWD |
| Terrain Adaptability | Indoor Flooring |
| Fork Width | 535mm |
| Fork Length | 1150mm |
| Operating Mode | Standing Operation |
| Fork Size | 535*1150mm |
| Capacity | 500KG |
| Load Centre | 400mm |
| Battery | 33AH |
| Drive Motor | DC12V/0.8Kw |
| Mast | 1 Stage |
| Colour | Red Yellow Orange Green |
| Rated Loading Capacity options | 500kg |
| Max. Lifting Height options | 1100mm 1300mm |
| Truck Type options | Semi Electric Self Loading Pallet Lift |
| Model | SES500 | |
|---|---|---|
| Capacity | Q(Kg) | 500 |
| Load centre | C(mm) | 400 |
| Type of lifting | Electric | |
| Operating type | Walkie | |
| Material | PU/Nylon | |
| Wheel base | y(mm) | 860 |
| Front wheel base | b11(mm) | 380 |
| Back wheel base | b10(mm) | 670 |
| Quantity Steering/Bearing/Balance | 2002-2-6 | |
| Bearing wheel size | mm | Φ70×60 |
| Steering wheel size | mm | Φ100×50 |
| Balance wheel size | mm | Φ40×26 |
| Training wheel size | mm | Φ30×26 |
| Min.fork height | mm | 90 |
| Max.fork height | h3(mm) | 1100 |
| Fork outside width | mm | 535 |
| Fork inside width | mm | 225 |
| Fork length | l2(mm) | 1150 |
| Single fork size | e/s(mm) | 155/60 |
| Overall length | L1(mm) | 1600 |
| Overall width | b1(mm) | 790 |
| Overall height | h1(mm) | 1400 |
| Whole height(after tape file shelf) | h4(mm) | 2700 |
| Min.turning radius | Wa(mm) | 1100 |
| Lifting speed(laden/unladen) | mm/s | 80/110 |
| Lowering speed(laden/unladen) | mm/s | 80/80 |
| Lift motor | Kw | 12V0.8 |
| Battery capacity | V/Ah | 12/33 |
| Battery weight | Kg | 10 |
| Net weight | Kg | 197 |
| Certificate | Number | Valid |
|---|---|---|
| 2006/42/EC | M.2026.206.C137529 | 30/03/2026 - 29/03/2031 |
| CE | M.2026.206.C134736 | 04/02/2026 - 03/02/2031 |
| EAC | — | 22/10/2023 - 22/10/2028 |
| CE | M.2023.206.C83216 | 22/03/2023 - 21/03/2028 |
| CE | M.2023.206.C83222 | 22/03/2023 - 21/03/2028 |
| CE | M.2023.206.C83221 | 22/03/2023 - 21/03/2028 |
Certificates are supplied with your quote on request.
